Scaling Legacy Systems: A Microservices Migration Journey with NestJS, AWS, and Azure

# Overview The e-commerce platform, built over a decade, had become a monolithic application that struggled to keep up with the increasing user base and feature demands. Deployment cycles were lengthy, and scaling specific functions required scaling the entire application. ## Challenge The monolithic architecture led to: - Long deployment cycles (average 2 weeks) - Difficulty in scaling individual components - High risk of system-wide failures due to tight coupling - Technological debt that hindered adoption of modern frameworks ## Goals The migration aimed to: - Decompose the monolith into independent microservices - Improve system scalability and resilience - Reduce deployment time and increase frequency - Enable teams to work autonomously - Adopt modern technologies and practices ## Approach The team adopted a strangler fig pattern, gradually replacing parts of the monolith with new microservices. Key steps included: 1. Domain-driven design to identify bounded contexts 2. Creating an API gateway for routing 3. Setting up CI/CD pipelines for each service 4. Implementing asynchronous communication via message queues 5. Establishing monitoring and logging solutions ## Implementation ### Technology Stack - **Backend**: NestJS (Node.js framework) for building microservices - **Cloud Providers**: AWS (ECS, RDS, S3) and Azure (Service Bus, Cosmos DB) for hybrid cloud benefits - **Containerization**: Docker and Kubernetes (EKS and AKS) - **CI/CD**: GitHub Actions with AWS CodeDeploy and Azure Pipelines - **Observability**: Prometheus, Grafana, ELK stack ### Service Decomposition The monolith was broken down into 12 microservices: - User Management - Product Catalog - Order Processing - Payment Gateway - Inventory - Notification - Recommendation - Search - Analytics - API Gateway - Auth Service - File Storage Each service was developed independently with its own database where applicable, following the database per service pattern. ### Communication - Synchronous: REST APIs and GraphQL for internal and external communication - Asynchronous: AWS SQS and Azure Service Bus for event-driven workflows ## Results After six months of migration: - **Deployment Frequency**: Increased from bi-weekly to multiple times per day - **Lead Time for Changes**: Reduced from 2 weeks to under 1 hour - **System Throughput**: Increased by 40% during peak load tests - **Error Rates**: Decreased by 70% due to fault isolation - **Operational Costs**: Optimized by 25% through right-sizing and reserved instances ## Metrics | Metric | Before | After | Improvement | |--------|--------|-------|-------------| | Deployment Time (avg) | 2 weeks | 1 hour | 96% faster | | System Uptime | 99.5% | 99.95% | 0.45% increase | | Page Load Time (avg) | 3.2s | 1.8s | 44% faster | | Concurrent Users Supported | 5k | 12k | 140% increase | | Incident Response Time | 45 min | 10 min | 78% faster | ## Lessons Learned 1. **Domain-Driven Design is Crucial**: Spend time upfront to understand business domains and boundaries. 2. **Invest in Observability Early**: Implement logging, monitoring, and tracing before distribution. 3. **Gradual Migration Reduces Risk**: The strangler fig pattern allowed continuous delivery of value. 4. **Automate Everything**: CI/CD pipelines are non-negotiable for microservices. 5. **Team Structure Matters**: Align teams with services to foster ownership. 6. **Hybrid Cloud Complexity**: Managing resources across AWS and Azure required careful networking and cost monitoring. 7. **Data Consistency Challenges**: Embrace eventual consistency and design compensating transactions. ## Conclusion The migration to microservices transformed the e-commerce platform from a fragile monolith to a resilient, scalable system. By leveraging NestJS for backend development and utilizing both AWS and Azure, the company achieved its goals of improved performance, faster deployments, and greater system resilience. The journey highlighted that while microservices introduce complexity, the benefits in agility and scalability are substantial when implemented with proper planning and execution.
